Mini Pivot Fixed Linear

Recessed, Surface, Pendant

With the same crisp and clean aesthetic as its Mini Pivot Track counterpart, Mini Pivot Linear fixtures are track-free lighting units that can be used in conjunction with Mini Pivot Track modules in comprehensive lighting designs, or they can serve as lighting solutions on their own for applications requiring uniform and consistent lighting effects throughout a space. Recessed, surface, or pendant mounted, Mini Pivot Linear delivers direct light distribution with HLO or DPO lensing options.

Specifications - Blank

Product TypesLinear, Track OpticsDPO™, HLO Distribution TypeBlank

Light Source

Static White

Custom array of mid-flux LEDs are cartridge-mounted with quick connect wiring to facilitate service and thermal management. Available in 2700K, 3000K, 3500K, 4000K, and 5000K with a minimum 80+ CRI and an option for 90+ CRI with elevated R9 value. Color consistency maintained to within 3 SDCM. LEDs operate at reduced drive current to optimize efficacy and lumen maintenance.

Optics

DPO™

The Diamond Prism Optic™ (DPO™) is our patent-pending 3-tiered optic meticulously crafted to refract and reflect beams with great precision, effectively keeping glare to a minimum while delivering light of exceptional quality and visual comfort.

HLO

The High-Efficiency Lambertian Optic (HLO) shielding of diffusing 0.075″ thick acrylic with up to 88% transmission and good source obscuration is combined with matte white side reflectors to create an efficient optical chamber with uniform luminosity. Luminaire brightness is controlled by the flux-to shielding area ratio.

Mini Pivot Fixed Linear

Recessed, Surface, Pendant

Specifications - DPO

Product TypesLinear, Track, Low UGR OpticsDPO™, HLO CCT/Light & ColorStatic White MountingRecessed Distribution TypeFixed, Direct, Direct/Indirect

Light Source

Static White

Optics

DPO™

HLO

Mini Pivot Fixed Linear

Recessed, Surface, Pendant

Specifications - HLO

Product TypesTrack, Track Module OpticsDPO™, HLO CCT/Light & ColorStatic White MountingRecessed Distribution TypeDirect, Direct/Indirect

Light Source

Static White

Optics

DPO™

HLO

MOUNTINGS

Pendant, Surface,
Recessed

WIDTH

0.9″

UP TO

95+ CRI

Linear fixtures

The Prism, equipped with our Diamond Prism Optic (DPO), emits a luxurious quality of light, soft and glare-free, wrapping around subjects with subtle graduated shadows.

The HLO represents a premium everyday solution with its elegance and distribution of clean, uniform light with smooth beam edges.

Mini Pivot Blank in the Fixed Linear group provides unlit aluminum sections that keep linear runs visually continuous while masking non‑illuminated areas, available in small length increments so designers can fine‑tune overall run dimensions and introduce intentional “quiet” segments without breaking the clean Mini Pivot aesthetic..
